HRC FUSE TKF315M400 MOTORRATED ED SF7 AM

315M400 TKF M fuse with a fixing centre. Motor-rated, for heavy machinery use. With a breaking capacity of 80 kA and voltage of 415V.

Features:

• Motor-rated fuse; for use where motors start-up currents are higher than the maximum continuous current. The first current is the continuous current, where the second one is the motor starting current.

Specifications:

• Size: 138 mm x 59 mm
• Fixing centre: 111 mm
• Amperage: 315M400
• Rated voltage: 415V
• Compliant with: BS 88

Applications:

• TKF M fuses are for use in industrial installations and can be fitted into BS 88 bolted fuse-holders and distribution fusegear.
