STORM 20 IP68 GLAND PACK 15.5-21mm OD images
STORM 20 IP68 GLAND PACK 15.5-21mm OD
M20 IP68 storm gland pack. SWA's storm range of cable glands are suitable for terminating armoured and non-armoured, SY and CY braided cable. Storm cable glands are a universal type of gland kit that can be used with a wide variety of cable including SWA and control cables. Fully water and dust resistant, making them ideal weather resistant option for terminated cables.
M20 IP68 storm gland pack. SWA's storm range of cable glands are suitable for terminating armoured and non-armoured, SY and CY braided cable. Storm cable glands are a universal type of gland kit that can be used with a wide variety of cable including SWA and control cables. Fully water and dust resistant, making them ideal weather resistant option for terminated cables.
Features:
- Pack contains:
- 2 glands
- 2 earth tags
- 2 brass lock nuts
- Fast-fit
- No need for a shroud
- Non-corrosive
- UV stabilised
- Zero-halogen
Specifications:
- Size: M20
- Cable entry: 15.5 mm to 21 mm
- IP rating: IP68
- Operating temperature: -20°C to 80°C
- Materials:
- Gland body, armour ring - brass
- Gland upper and lower body - PAS66 30% GF
- Gasket and O-rings - NBR
- Approval: BS EN 62444: 2013
-
ReferenceLPAST20
