SCHNEIDER A9D11810 10A C RCBO

The Schneider Acti 9 iC60 A9D11810 is a 10A, single-pole, C-type miniature circuit breaker (MCB).

Specifications:

• Characteristic curve: C
• Rated current: 10A
• Rated voltage: 400V AC
• Rated frequency: 50 Hz / 60 Hz
• Number of poles: 1
• Operating temperature: -15°C to 60°C
• Mounting: DIN rail
• Size: 110 mm x 77.5 mm x 18 mm
• Standards: BS EN 61009-1, IEC 61009-1, IEC 61009-2-2, AS/NZS 61009.1
