2.5mm 7-CORE SY CABLE images
2.5mm 7-CORE SY CABLE
2 mm² 3-core SY flexible control cable, sold by the metre. SY cable has a braid of galvanised steel wire, and is suited to installations with medium to high mechanical stress, with a voltage rating of 300 / 500V.
2 mm² 3-core SY flexible control cable, sold by the metre. SY cable has a braid of galvanised steel wire, and is suited to installations with medium to high mechanical stress, with a voltage rating of 300 / 500V.
Specifications:
- Size: 2 mm²
- Outer sheath colour: Transparent
- Voltage: 300V to 500V
- Insulation: PVC (polyvinyl chloride)
- Bedding: PVC (polyvinyl chloride)
- Screen: GSWB (galvanised steel wire braid)
- Standards: VDE0250
Applications:
- Control cable to connect equipment in production / assembly lines
- Can be used between both fixed and mobile equipment, and air conditioning systems
- Suitable for use in dry, moist and wet rooms
- The galvanised steel wire braid serves as protection against mechanical traverse loads and acts as a magnetic screen against interference
- These cables are not used for outdoor or underground installation
-
ReferenceCBLSY2.5X7C
