EUC3-40-4P 40A CONTACTOR 4-POLE H+L 230V AC COIL NO

The Europa EUC3-40-4P is a 40A, 4-pole modular contactor (DIN rail mounting), normally open (N/O) with a 230V AC coil.

Specifications:

• Rated current: 40A
• Number of poles: 4
• Rated insulation voltage: 500V AC
• Rated operating voltage: 400V AC
• Rated operating current AC1: 40A
• Rated operating current AC3: 25A
• Rated power AC1: 28 kW
• Rated Power AC3: 12 kW
• Rated terminal capacity: 2.5 mm² to 25 mm²
• Rated terminal capacity (coil): 0.75 mm² to 2.5 mm ²
• Width: 54 mm
• Mounting: 35 mm DIN rail
