HRC FUSE TIS 63 M80 BAO SB4 AM

80M100 TIS M fuse with a fixing centre. Motor-rated, for heavy machinery use. With a breaking capacity of 80 kA and voltage of 690V.

Features:

• Motor-rated fuse; for use where motors start-up currents are higher than the maximum continuous current. The first current is the continuous current, where the second one is the motor starting current.

Specifications:

• Size: 87mm x 21 mm
• Fixing centre: 73 mm
• Amperage: 80M100
• Rated voltage: 690V
• Compliant with: BS 88

Applications:

• TIS M fuses are for use in industrial installations and can be fitted into BS 88 bolted fuse-holders and distribution fusegear.
