SCHNEIDER LC1K0901U7 240V AC 9A MINI CONTACTOR

This 3 NO, 240V AC, 9A mini contactor is a switch used for switching an electrical power circuit.

Specifications:

• Voltage: 240V AC
• Amperage: 9A
• Auxiliary contact composition: 1 NC
• Size: 57 mm x 58 mm x 45 mm
• IP rating: IP20 conforming to IEC 60529
• Motor Power kW: 2.2 kW at 220...230 V AC 50/60 Hz AC-3
• Motor Power kW: 4 kW at 380...415 V AC 50/60 Hz AC-3
• Motor Power kW: 4 kW at 440 V AC 50/60 Hz AC-3
• Motor Power kW: 4 kW at 480 V AC 50/60 Hz AC-3
• Motor Power kW: 4 kW at 500...600 V AC 50/60 Hz AC-3
• Motor Power kW: 4 kW at 660...690 V AC 50/60 Hz AC-3
• Motor Power kW: 2.2 kW at 400 V AC 50/60 Hz AC-4
