Differential Thermal Overload Relay

SCHNEIDER LR2K0307 1.2-1.8A OVERLOAD

This 1.2A to 1.8A differential thermal overload relay is used for preventing motor damage by monitoring the current in the circult of the motor and breaking the circuit when an electric overload or phase failure is detected.

This 1.2A to 1.8A differential thermal overload relay is used for preventing motor damage by monitoring the current in the circult of the motor and breaking the circuit when an electric overload or phase failure is detected.

Specifications:

  • Amperage: 1.2A to 1.8A
  • Voltage: 690V AC
  • Poles: 1 NO + 1 NC
  • Size: 65 mm x 58 mm x 45 mm
  • IP rating: IP2x conforming to IEC 60947

  • Reference
    TELR2K0307
