G/MASTER 440G-T27127 TLS2-GD2 I/LOCK SW 2NC-1NO 24V POWER TO LOCK

Guardmaster 24V AC/DC 440G-T series solenoid interlock switch, power to lock. This safety switch is positive mode and tongue operated, and provides electrical interlocking of the machine's safety guard to the control circuit. When the door is open power to the machine is isolated, ensuring that personnel cannot access dangerous machinery while it is running. It also keeps the safety barrier securely locked while machinery is in motion, reducing risk of injury. It works by securing the tongue in the switch when power is applied to the solenoid. The mechanism is released when power is removed, which allows the tongue to be extracted. Note: Actuator is not supplied.

Specifications:

Exceptional security and stability due to high locking force of 2000N (450 lb)
Convenient rotatable head with 2 entry slots, 4 possible actuator entry positions, blanking plug provided to seal the unused slot
Fast troubleshooting with lid mount status indication
Ideal for use with hinge, sliding, and lift-off doors
